Some radio menu items can be set using RS-BA1 menus. RS-BA1 works well with the Windows screen magnifier utility. The size is not adjustable, and it is not affected by the screen dpi setting. The radio panel window is 6.0" H x 7.8" W on a typical 22" display. Left/right mouse click on a knob to turn it counter-clockwise or clockwise, respectively. RS-BA1 graphical user interface for an Icom 746PRO. The graphical user interface for the Remote Control Program is shown in Figure 1.įigure 1.
RS BA1 SOFTWARE WITH HRD SERIAL
Serial adapters with FTDI chipsets are reportedly much more reliable. The RS-BA1 Remote program worked with the adapter, but the direct CI-V connection to the radio failed intermittently. I also tried a less expensive serial-USB adapter with a Prolific Technology chip. For this article, the level converter (Radio port) in a MicroHam USB Interface III was used to connect the transceiver CI-V jack to a USB port on my computer.
Newer radios in the list also have either an RS-232 jack or a USB connector to use instead of the CI-V jack.Ī TTL level converter is required for a CI-V connection. Connecting the Radio to a ComputerĪll supported radios have a CI-V remote control jack for the serial connection to a computer. Icom America loaned the RS-BA1 software for this review. There are also general sets of controls in the program that might work with older Icom radios.
RS BA1 SOFTWARE WITH HRD HOW TO
The Instruction Manual explains how to set up the serial connections for both programs.
(A base station server is not required for an IC-7700 with firmware version 2.0 or later.) In that case, a second computer (server) is located at the transceiver. The Remote Utility handles remote communication over the Internet. When the control computer is connected directly to the radio, only the Remote Control program is required. It consists of two programs-Remote Control and Remote Utility-each with an icon on the Desktop.
RS BA1 SOFTWARE WITH HRD WINDOWS 7
The RS-BA1 software runs on Windows XP(SP3), Vista, and Windows 7 systems. Using RS-BA1 with a screen reader is described in another article. The basics of rig monitoring are described in a separate article using Ham Radio Deluxe in the examples. This article is for vision-impaired amateur radio operators who want to use RS-BA1 to display the settings of an Icom HF transceiver on a computer screen for improved visibility. Icom RS-BA1 software makes it possible to monitor and control Icom transceivers either locally or remotely.
